diameter of the wire line 7/8 "(22mm), 1" (25.4mm), 118 "(28.5mm), 114" (31.75mm) |
|
maximum dead rope tension (213.5KN): 48000LBS |
|
accuracy of weight indicator: ± 1.0%FS and ± 1.5%FS |
|
accuracy of the system: ± 2.0%FS (sensor pairs and the weight indicator) |
|
instrument piping system shall not be leaking in the under the maximum working pressure; |
|
working temperature: -40 ℃ ~ 55 ℃; |
|
Note: the instrument pressure transmission medium for CW-15 hydraulic oil |
